VIQUA VH200-F10 UV Mini Rack System l Part# VH200-F10
$860.02
SKU: VH200-F10
Categories: UV Disinfection, UV Systems
Description
Product Details:
- Powerful, yet compact UV disinfection system with pre-filtration designed for the average size home or cottage, for flow rates up to 9 gpm
- Adds integral 5 micron pre-filter module to the VH200 UV system
- Mounted on a reversible, heavy duty, painted steel bracket for installation flexibility and convenience
- Suitable for applications with water flow rates up to 9 gpm
- 10 ” Big Blue filter housing & 5 micron sediment filter included.
- 3 piece high-flow filter housing
- Wrench for filter housing included
- Includes pressure relief button to reduce pressure in housing when changing cartridge.
Filters Used:
- 10″ Big Blue filters (4.5″ x 10″)
UV Specifications:
- Part # VH200-F10
- Flow Rate: 9 gpm
- Connection Size: 3/4″ FNPT / 3/4″ MNPT
- Power Consumption: 35 Watts
- Replacement Lamp: S200RL-HO
- Replacement Sleeve: QS-001
Water Quality Requirements:
- Hardness: < 7 grains ( 120 mg/L)
- Iron: < 0.3 mg/L
- Tannings: < 0.1 mg/L
Additional information
Weight | 26 lbs |
---|---|
Dimensions | 17 × 11 × 19 in |
